R.H.S. Pipes

Size	Thickness	Kg. Per Mtr.
26 X 13	1.2	0.70
	1.4	0.83
	1.6	0.93
40 X 20	1.2	1.10
	1.4	1.25
	1.6	1.40
	1.8	1.60
	2.0	1.80
	2.5	2.25
40 X 25	1.2	1.25
	1.4	1.40
	1.6	1.6
	1.8	1.75
	2.0	2.0
	2.5	2.38
50 X 25	1.2	1.38
	1.4	1.6
	1.6	1.83
	1.8	2.0
	2.0	2.33
	2.5	2.83
75 X 25	1.2	1.83
	1.4	2.16
	1.6	2.45
	1.8	2.66
	2.0	3.0
	2.5	3.77
60 X 40	1.2	1.83
	1.4	2.16
	1.6	2.45
	1.8	2.66
	2.0	3.0
	2.5	3.77
80 X 40	1.2	2.25
	1.4	2.58
	1.6	2.95
	1.8	3.33
	2.0	3.66
	2.5	4.55
122 X 61	2.0	5.66
	2.5	7.0
40 X 10	1.2	0.91
	1.4	1.05
	1.6	1.2
50 X 15	1.2	1.2
	1.4	1.38
	1.6	1.58
RXT	1.2	1.74
	1.4	2.02
	1.6	2.38
95 x 25	1.8	3.33

S.H.S. Pipes

Size	Thickness	Kg. Per Mtr.
15 X 15	1.2	0.53
	1.4	0.66
	1.6	0.71
20 X 20	1.2	0.75
	1.4	0.83
	1.6	0.91
	1.8	1.08
	2.0	1.25
25 X 25	1.0	0.75
	1.2	0.91
	1.4	1.08
	1.6	1.20
	1.8	1.33
	2.0	1.46
	2.5	1.8
32 X 32	1.2	1.17
	1.4	1.35
	1.6	1.55
	1.8	1.72
	2.0	2.0
	2.5	2.33
40 X 40	1.2	1.41
	1.4	1.58
	1.6	1.9
	1.8	2.16
	2.0	2.33
	2.5	3.0
50 X 50	1.2	1.83
	1.4	2.16
	1.6	2.45
	1.8	2.75
	2.0	3
	2.5	3.75
60 x 60	1.2	2.25
	1.4	2.58
	1.6	2.95
	1.8	3.33
	2.0	3.66
	2.5	4.58
72 X 72	1.6	3.6
	1.8	4
	2.0	4.41
	2.5	5.5
	3	6.5
100 X 100	2.0	6.16
	2.5	7.66

Round Pipes

Size	Thickness	Kg. Per Mtr.
15mm ½	1.2	0.58
	1.4	0.66
	1.6	0.75
	1.8	0.83
	2.0	0.95
20mm 3/4	1.2	0.7
	1.4	0.83
	1.6	0.93
	1.8	1.05
	2.0	1.25
25mm 1”	1.0	0.75
	1.2	0.91
	1.4	1.08
	1.6	1.21
	1.8	1.36
	2.0	1.58
	2.5	1.88
32mm 1 ¼	1.0	1
	1.2	1.2
	1.4	1.4
	1.6	1.6
	1.8	1.78
	2.0	2
	2.5	2.33
40mm 1 ½	1.2	1.37
	1.4	1.6
	1.6	1.83
	1.8	2.05
	2.0	2.33
	2.5	2.83
50mm 2”	1.2	1.75
	1.4	2
	1.6	2.33
	1.8	2.58
65mm 2 ½	2.0	2.91
	1.4	2.58
	1.6	2.93
75mm 3”	1.8	3.33
	1.6	3.41
	1.8	3.83
	2.0	4.24
100mm 4”	2.5	5.26
	1.6	4.43
	1.8	5
	2.0	5.52
